Solid Level Sensors

<<< Back to Sensors

Solid Level Sensors


Continuous Level


  • Real-Time Continuous Output
  • Focused / Directed Energy Field
  • TDR Technology Unaffected by Dust, Bulk Density and Temperature
  • No Moving Parts
  • Smart RS-485 and/or Analog Output
  • Measuring Range (Dependent on Target Material Dielectric Constant):
    • Up to 100ft (30m) for Solids
    • Up to 200ft (60m) for Liquids
  • Sensor Performance Unaffected by Material Composition
  • On-Demand Measurement, Operated Manually or Automatically, with Lock Out Override
  • Virtually Maintenance Free
  • Smart Sensing Reliability Combining Optic and Hall-Effect Technologies
  • Smart RS-485, Analog or Pulse Output
  • Measuring Range Up to 150 ft (46m)




Point Level



  • Self–Validating “TRUE” Fail-Safe Design with Microcontroller-Based Reliability
  • Patented Magnetic Sensing Technology
  • Maximized Sensor Life via Motor Shut-Off Feature
  • Externally Viewable LED Sensor Status Indicator (Except Hazardous Location Units)
  • Independent Sense and Fault Outputs
  • Enclosure Provides Ample Wiring Access and a Twist ON/OFF Cover
  • Basic Electro-Mechanical Operation
  • Maximized Sensor Life via Motor Shut-Off Feature
  • DC Powered Models Use Longer Life AC Motor
  • Economical and Versatile
  • Enclosure Provides Ample Wiring Access and a Twist ON/OFF Cover
  • Maximized Reliability via Smart Sensing Algorithms Including “Self-Validating” Fail-Safe Protection
  • Simple, Convenient Push-Button Calibration and Test
  • Driven Shield Technology Overcomes Material Build-up
  • Externally Viewable LED Sensor Status Indicator (Ordinary Loc. Unit)
  • Universal Power Supply
  • Superior 0.5pF Sensitivity
  • Enhanced Temp. Compensation
  • Economical Design
  • Potentiometer-Adjusted Calibration / Sensitivity and Delay
  • Driven Shield Technology Overcomes Material Build-up
  • xternally Viewable LED Sensor Status Indicator (Ordinary Loc. Unit)
  • Superior 0.5pF Sensitivity
  • Temperature Compensation



  • Compact Potted Packaging
  • Versatile Application Sensing
  • Electronic Solid State Outputs
  • AC Model (PAC-30U) in 2-Wire Series Configuration
  • DC Models (PDC-30) in 3-Wire Sinking / Sourcing Configurations
  • Field Selectable Normally Open or Normally Closed
  • Economical
  • LED Status Indicator
  • Adjustable Calibration
  • Unaffected by Changes in Environment and Materials
  • Exceptional Sensitivity with No Calibration Required
  • Diamond Shape Single-Probe Design
  • Universal Power Supply
  • Fail-Safe on Power Failure
  • Variable Time Delay
  • Economical Design
  • Unaffected by Changes in Environment and Materials
  • Good Sensitivity with No Calibration Required
  • Single-Probe Design
  • Universal Power Supply
  • Fail-Safe on Power Failure
  • Local Status Indicating Light
  • Twist On/Off Cover



  • Basic Pressure-Sensing Operation
  • Electrically-Passive Sensing Method
  • Reliable, Durable, and Low Maintenance Operation
  • Low-Profile, Non-Intrusive Mounting
  • Adjustable Sensitivity
  • Over-Pressure Protection
  • Basic Angular-Sensing Operation
  • Electrically-Passive, Mercury-Free Sensing Method
  • Durable, Low Maintenance and Low-Cost Performance
  • No Calibration Required…Output Switch Closes When Tilted Approximately 17
  • Easily Adjustable Sensing Point by Repositioning Hanging Height





Solids Flow

  • Non-Contact Flow Detection
  • Non-Intrusive Flush Mounting
  • Excellent Sensitivity
  • Externally Viewable LED Sensor Status Indicator (SFD-2)
  • Maintenance Free – No Moving Parts
  • Relay Output (SFD-2) or Analog Output (SFI)
  • Hazardous Location Approvals for Dust (Sensors Only)

Particle Emission

  • Economical Sensing Alternative to Opacity Detection
  • Exceptional and Reliable Sensitivity via Proven Triboelectric Technology
  • Relay Output with Sensitivity Adjustment, Signal Smoothing and Time Delay Functions
  • Quick-Disconnect Connector

Bin Aeration

  • Aeration Alternative to Vibration
  • Quiet, Inexpensive, Non-Electrical Aeration Solution
  • Simple Designs Facilitate Trouble-Free Operation
  • Evasser/Flo-Pad Provides An Air Flow That Tends to Sweep the Vessel Wall
  • Air Pad Comes in the Industry-Standard Low-Profile Footprint











  สอบถามข้อมูลเพิ่มเติมเกี่ยวกับสินค้า หรือปรึกษา
Sales Engineer สามารถติดต่อได้ที่

Tel: 02 10 50 555
